Cytac Shotshell Carrier Remington 870

Shotshell Carrier

Compatible With Remington 870, 1100 & 11-87, Etc.

12GA Shotguns

Shotshell Carrier holds 6-round 12GA shots. It is mounted to Remington shot gun for easy access and fast reload.

Material: Military Grade Polymer

Available Range: Training, Competition, or Hunting Use

FEATURES

· Lightweight, polymer shotshell carrier.

· Easy installation, requires no alterations to the shotgun in most cases.

· All mounting screws are included, no gunsmithing required

KIT

· two Allen Key of different size.

· a 10/32 screw with washer.

· a 1/4-28 screw with washer

INSTALLATION GUIDE:

1. Remove 6 little hex screws from the shotshell carrier to expose two tapped hole in the mounting plate.
2. Lay the shotgun on its side with the ejection port facing down.
3. Using the supplied big screw with washer, push out pin (A) located above and to the rear of the trigger guard. Leave screw in hole.
4. Turn the shotgun over and place the mounting plate on the receiver with the two corresponding holes on the two screws.
5. Start screws into the mounting plate and lightly tighten. Do not overtighten. Overtightening may lock up the shotgun’s action. To remedy, simply loosen screws.
